Name: Guchen BTMS - Electric Bus Battery Pack Cooling System
Brand: GUCHEN
Rating: 5 (30 reviews)

GCB Series Independent Battery Thermal Management System

Model:

GCB

Cooling Capacity:

4-8KW

HV power supply:

DC400V-DC750V

Refrigerant:

R134a/R407c

Optional:

PTC heater

Introduction of GCB series battery thermal management system

It is an Independent BTMS with major function to keep the battery temperature within its nominal operating temperature.
The BTM system consists of an electric scroll ac compressor, Danfoss heat exchanger, SPAL brushless fan and quality water pump. It can efficiently dissipate heat from the battery pack. The BTMS is designed to meet the high-temperature compatible requirements of electronic components, and can maintain a constant temperature inside the battery cabinet by controlling the airflow between batteries.

Standard Configuration of GCB series Battery Pack Cooling System

◆ CAN2.0 communication. ◆ PTC water heater (6-14kw) is optional. ◆ There are four essential "work modes": standby mode, cooling mode, heating, and cycle mode.

◆ It is a liquid cooling system. ◆ Different models of battery thermal management systems offer different ranges of capacity. 3 Models are available with a cooling capacity range of 3kw to 8kw for your needs.

◆ Fault self-diagnosis function. ◆ Power data real-time upload. ◆ Meeting EMC compliance requirements

To Make Better Choices, Look at More Available Options at Guchen Industry

GCED Series Independent Battery Chiller for E-Bus

Model:GCED

Cooling Capacity:8KW/13KW

HV power supply:DC400V-DC750V

Quote Now

EDHO-01 Electric Bus Defroster | Heating Only

Model:EDHO-01

Heating Capacity5KW

Evaporator Air Volume700m³/h

Quote Now

All Electric Bus Air Conditioner

Product Name:A/C for All-electrical Bus, Tramway, Trolleybus

Driven Type:Vehicle Electric or Battery

Installation:Rooftop Mounted

Quote Now

Technical Parameters of Guchen BTMS for Electric Bus

Product model	GCB-050C	GCB-080C	GCB-095C	GCB-135C
Refrigerating capacity	5KW	8KW	9.5KW	13.5KW
Minimum inlet water temperature	10	10	10	10
Condensing air volume,m³/h	2000	4000	4000	6000
Pump head,m	12	24	24	24
Coolant	Glycol	Glycol	Glycol	Glycol
High voltage range	DC350-750V or 250-450V	DC350-750 or 250-450V	DC350-750V or 250-450V	DC350-750V or 250-450V
Cryogen	R134a	R407c	R407c	R407c

More Details of Guchen BTM System

Why is Battery Thermal Management System a Necessity in Electric Bus?

The battery is one of the most important components of an electric vehicle, and it needs to be protected from overcharging and overheating.
The goal of a battery thermal management system is to keep the temperature of the battery pack at an optimal level for charging, discharging and storage. When properly installed, this system will help extend the life of electric bus batteries by reducing wear and tear on the cells caused by heat.
This is especially important 1) when charging electric city bus overnight, and 2) when the electric bus is driven in hot weather or under load for extended periods of time, as high temperatures will damage the batteries faster than anything else. The best way to prevent this is by installing a high-quality battery cooling system that can protect the battery packs from extreme temperatures.
