Name: Battery Management System For Electric Vehicles
Brand: GUCHEN
Rating: 5 (80 reviews)

3KW Electric Vehicle Thermal Management System

Model:

GC03-CS01

Rated cooling capacity ( kw )

3KW

Heating capacity

optional

Dimensions

530 ( L )* 446 ( W )* 365 ( H )

Battery thermal management system for electric vehicles

Our battery thermal management safeguards your batteries with precise temperature control, advanced real-time monitoring, and robust protection mechanisms against overloads, pressure fluctuations, and other critical risks. From increasing battery life to enhancing operational efficiency, it’s a complete package tailored to keep your electric vehicles running at their best.

Guchen understands that every electric vehicle operates under unique conditions, and that’s why our battery thermal management system is engineered for flexibility. No fixed outputs, no one-size-fits-all approach—your needs define our design.

What You’ll Gain Here:
- Insights into scalable and adaptable BTMS solutions for electric vehicles
- Tools to maintain battery health and ensure long-term efficiency.
- A partner ready to craft solutions that align perfectly with your goals.

We’re here to support you in achieving batter ev thermal management system.

Why It’s a Perfect Fit

More than just a cooling solution, our BTMS system incorporates advanced algorithms to monitor battery health, adjusting cooling efforts in real time based on load conditions and thermal stress, thus extending battery life and maintaining peak performance.

Advanced energy management features enhance the balance between power consumption and cooling capacity, delivering high performance while minimizing energy waste.

Zero Compromise on Safety: Engineered with multiple layers of safety, our battery cooling system proactively monitors critical parameters to prevent overheating and minimize the risk of thermal runaway, ensuring that both your vehicles and operators remain safe in extreme conditions.

To Make Better Choices, Look at More Available Options at Guchen Industry

TBTM-15 Battery Management System for Heavy Truck

Product Name:TBTM-15

Refrigerant:R134a

Protection Lever: IP67

Chat Now

Battery Thermal Management System for Construction Machinery

Chat Now

Battery Thermal Management-8kw water-cooling unit

Model:NB231201

Refrigerating output:8.0kW

Box color:Black / silver

Chat Now

3kw battery thermal management system technical parameters

Model	GC03-CS01
High voltage power supply	75~120 VDC 110~180 VDC 230~420 VDC 400~750 VDC 600V~950VDC (voltage range adjustable)
Low voltage power supply	18V-32V
Built-in water pump	11m&1800l/h
Waterproof grade	IP67
Refrigerant	R134a
Coolant Type	50%/50% ethylene glycol and water solution
Unit fixing point	Φ12 holes * 4
Connectors	Inlet and outlet pipe Φ20
Electronic control	According to customer needs

Guchen Battery Thermal Management in electric Vehicle Applications

Product highlights

Developed based on pure electric/hybrid commercial vehicles, the unit can be flexibly arranged on the frame and chassis.
Safe and reliable
● The unit adopts metal frame structure, and passes CAE analysis and vibration test to meet the reliability requirements.
requirements.
● PTC liquid heater can be configured with standby, cooling, heating and self-circulation modes.
Self-circulation mode.

Advantages and features

● CAN2.0 communication access, easy to group network control;
● EMC meets the requirements of Class I.
● Real-time uploading of information, fault self-diagnosis and many other advantageous functions, reaching the advanced level in the industry.
